1PCS MRF6S9130H RF Power Field Effect Transistors 880 MHz 28 V 27W new original
Specifications
| Return Shipping Will Be Paid By | Seller |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 60 Days |
| Refund Will Be Given As | Money Back |
| MPN | MRF6S9130HR3 |
| Brand | FREESCALE |
Part No. : MRF6S9130HR3 MRF6S9130H Description : RF Power Field Effect Transistors N-Channel Enhancement-Mode Lateral MOSFETs 880MHz ， 27W , 28V Designed for N - CDMA, GSM and GSM EDGE base station applications with frequencies from 865 to 960 MHz. Suitable for multicarrier amplifier applications. • Typical Single-Carrier N-CDMA Performance @ 880 MHz: VDD = 28 Volts, IDQ = 950 mA, Pout = 27 Watts Avg., Full Frequency Band, IS-95 CDMA (Pilot, Sync, Paging, Traffic Codes 8 Through 13) Channel Bandwidth = 1.2288 MHz. PAR = 9.8 dB @ 0.01% Probability on CCDF. Power Gain ó 19.2 dB Drain Efficiency ó 30.5% ACPR @ 750 kHz Offset ó -48.1 dBc in 30 kHz Bandwidth GSM Application • Typical GSM Performance: VDD = 28 Volts, IDQ = 950 mA, Pout = 130 Watts, Full Frequency Band (921-960 MHz) Power Gain ó 18 dB Drain Efficiency ó 63% GSM EDGE Application • Typical GSM EDGE Performance: VDD = 28 Volts, IDQ = 950 mA, Pout = 56 Watts Avg., Full Frequency Band (921-960 MHz) Power Gain ó 18.5 dB Drain Efficiency ó 44% Spectral Regrowth @ 400 kHz Offset = -63 dBc Spectral Regrowth @ 600 kHz Offset = -75 dBc EVM ó 1.5% rms • Capable of Handling 10:1 VSWR, @ 28 Vdc, 880 MHz, 130 Watts CW Output Power Features • Characterized with Series Equivalent Large-Signal Impedance Parameters • Internally Matched for Ease of Use • Qualified Up to a Maximum of 32 VDD Operation • Integrated ESD Protection • Lower Thermal Resistance Package • Low Gold Plating Thickness on Leads, 40μ″ Nominal. • RoHS Compliant • In Tape and Reel. R3 Suffix = 250 Units per 56 mm, 13 inch Reel. Maker： FREESCALE Payment We accept PayPal only.All major credit cards are accepted through secure payment processor PayPal.Payment must be received within 7 business days of auction closing.We ship to your eBay or Paypal address. Please make sure your eBay and Paypal address is correct before you pay.Delivery detailsItem will be shipped out within 48 hours upon receipt of your payment.The shipping time details, please read the shipping and delivery together with the price.We ship to your PayPal address. Please make sure your PayPal address is correct before you pay.Considering the cost of business and easy shipping, usually the item is packed in retail packaging.Terms of saleAll the products we are selling include factory warranty, don?t cover items that have been abused, burned and damaged in any form.Please contact us via eBay Message if you have NOT received item in 30 days, we will check it with post office, and then resend or refund any missing item.In the unlikely event that your product is faulty in anyway, you must contact us ASAP and then return it within 7 days of receipt. The postage and packing fee will NOT be refunded.We will not be responsible for the delivery or insurance charges incurred in returning item back to us.If you return an item purchased from us, it must be back in Factory Condition. This includes packaging, inserts, manuals etc. please allow us to 5 Working Days for us to process your returned item.About usIf you have any questions, please fee free to email our service specialists 24 Hours a Day, 7 Days a Week.We will reply you ASAP. If no response within 24 Hours, please check the spam in your mail box.We greatly appreciate your POSITIVE feedback. Please do NOT leave negative feedback without asking for help.Contact usPls contact us through ebay message or email.
