【USA】800W 0.8KW Air-cooled Spindle Motor ER11 220V 65mm 24000RPM For CNC Router
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Cooling | Air-cooled |
| Special Motor Construction | Spindle Motor |
| VFD Phase | 3 phase |
| Size | Diameter 65mm |
| Operating Speed | 0-24000rpm/min |
| Runout Off | Less than 0.01mm |
| MPN | Does not apply |
| Material | Stainless Steel |
| Bearing | 4pcs Ceramic bearing |
| Brand | RATTM MOTOR |
| Unit Type | Unit |
| Collet | ER11 collet |
| Frequency | 400Hz |
| Lubrication | Grease |
| Country/Region Of Manufacture | China |
| Application | Milling |
| Power & Voltage | 800W 0.8kw, 220V |
【USA】800W 0.8KW Air-cooled Spindle Motor ER11 220V 65mm 24000RPM For CNC Router From our USA warehouse within one days handing time via UPS delivery to USA (other countries by standard ship from China) Package include: 1 x 0.8Kw 800W Quanlity Air-cooled spindle motor(ER11,220V,24000rpm,dia 65mm,4 bearing,400Hz) 0.8KW ER11 Air-cooled Spindle motor Engraving milling GrindSpecification:Material:Stainless SteelSize:Φ65mmPower:0.8KwVoltage:220VACCurrent:4AFrequency:0-400HzSpeed:10-24000rpmCooling:Air-cooledRunout off:Less than 0.01mmPrecision tapered bore:Less than 0.005mmBearing Lubrication:GreaseCollet size:ER11Bearings:4 Ceramic bearingNet Weight:2.85kgPower supply interface:Professional aviation Interface, Interface 1234 marked 123 respectively connected to the inverter output end of the (U, V, W), 4 ground wire this interface must be safe ground. Main application:Wood, Aluminum, Stone, metal, glass, PVC industry 1. Structural features 1) High speed electric main bearing all adopt the Ceramic bearing, axis sets of loading, Improve spindle in the high-speed rotation supporting stiffness and precision grinding. 2) Before driving, rotation of the shaft by hand.Spindle high speed rotation caused by temperature rise, use of cooling liquid circulating system to eliminate. 2. Instructions for use 1) In use, must first connect the cooling water pipe, make spindle connect cooling water and then start. 2) Before driving, turned by hand spindle. If sensory block is not flexible, you should troubleshoot, and then check the direction of rotation of the spindle from the spindle end to see if the match should rotate counterclockwise power wiring should be changed to make it consistent. 3) Before driving, cooling water for grinding workpiece can’t be in the front end of the spindle cover, to prevent the front bearing cover slot inlet burning motor and bearing. the motor must not enter the water, after turned on of the motor, when you live in grinding the workpiece to open the grinding of workpieces coolant. First off the workpiece coolant shutdown, and then close the spindle motor. 3. Maintenance and Service 1) Motorized spindle by medium frequency power supply rated voltage, frequency should be consistent with electric spindle technology parameters, motorized spindle rotational speed can change the frequency to adjust, also directly proportional voltage change. 2) When the spindle is temporarily not in use, should use compressed air to blow the coolant water,to avoid rusting, plug the hole. Spindle surface should be coated with anti rust oil. The shaft end protecting device, placed in dry place.3) If replacement the spindle of bearings, best professional and technical personnel from the replacement. Use special tools, stator coil does not to be removed. ShippingPlease open the package and check if there are some damages before sign, if there are some damages , please do not sign and contact us immediatelyWe ship to worldwidebut If your country’s custom is strict, please contact us before you bid to check detail and confirmed.Delievry timeUSA post service round 10-18 business daysCanada China post round 25-40 business daysAustralia China post round 20-35 business daysWestern EU(Germany,UK,France, etc) China post 20-35 business daysAsia,South America,other countries Chins post round 15-40 business daysNote:above offer is default delivery way,if you need fast delivery like as DHL/UPS or post service pls inform us to confirm the shipping cost before you bidAbove DHL/UPS offer is without remote fee,if your post code is remote it need extra cost.All items will be shipped within 1-3 business days upon receipt of paymentPaymentWe accept paypal payment,all Paypal must be confirmed(shipping and billing address must match and correct and it need tell us your telephone no for delivery)Payment must be made within 48hours of the auction end timeImport duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer responsibility.Problem&FeedbackPlease give us the opportunityto resolve any problem when you have,we concern your problem and we will try our best to resolve it.We are a new member in ebay now,and need understand both of sidesPls email us before you want to leave any negative feedbackRefundWhen you have the parcel,and not satisfied the goods or it is other problem like as broken,pls tell us the detail reason and provide the photos,after confirm we will refund your money,but the delivery charge paid by buyer.Contact usWelcome worldwide customer inquire and questions,we will try to do our best to feedback customer’s email within 1-2 business days,if not pls check the mail box againCustomer’s satisfaction is very important to us. 0.8KW/ 800W Air Cooled Spindle Motor ER11 220V for CNC Router Milling Machine800W/0.8Kw Air cooled spindle motor ER11 220V 65x225mm for CNC ENGRAVING GRIND0.8KW/ 800W Air Cooled Spindle Motor ER11 220V for CNC Router Milling Machine0.8KW/ 800W Air Cooling Cooled Spindle Motor for CNC Router Milling Machine 220V0.8KW/ 800W Air Cooling Cooled Spindle Motor for CNC Router Milling Machine ER110.8KW 800W Air Cooled Cooling Spindle Motor ER11 for CNC Router Milling Machine0.8KW 800W Air Cooled Cooled Spindle Motor ER11 24000RPM for CNC Router Machine0.8KW 800W Air Cooled Spindle Motor ER11 24000RPM 220V for CNC Router Machine0.8KW AIR-COOLED SPINDLE MOTOR ENGRAVING MILL GRIND FOUR BEARING FOR CNC ER110.8KW/ 800W Air Cooled Spindle Motor ER11 400HZ 220V for CNC Router Machine 220VNew 800W 0.8KW Air Cooled Spindle Motor ER11 220V 400Hz ENGRAVING MILLING GRINDCNC 800W 0.8KW Air Cooled Spindle Motor ER11 220V 400Hz ENGRAVING MILLING GRIND0.8kw Quanlity Air cooled runout-off 0.01mm ER11 220V Spindle motor For CNC MillQuanlity 0.8kw 800W Air cooled runout-off 0.01mm ER11 220V Spindle motor For CNCQuality 0.8KW 800W Air Cooled Spindle Motor ER11 24000RPM 220V/AC for CNC RouterQuality 0.8KW 800W Air Cooled Spindle Motor ER11 220V/AC 24000rpm for CNC Router800W/0.8Kw Air cooled spindle motor ER11 220V 65x225mm for CNC ENGRAVING GRINDQuanlity 0.8kw 800W Air cooled Spindle motor runout-off 0.01mm ER11 220V For CNCQuality 0.8KW 800W Air Cooled Spindle Motor ER11 24000rpm 65mm Engraving Milling
