TLV3501 Voltage Comparator Sinusoidal to Square Wave TTL Level Signal Output
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Modification Description | Does Not Apply |
| Bundle Description | Does Not Apply |
| MPN | Does Not Apply |
| Model Number | TLV3501 |
| Brand | EC Buying |
| Type | Voltage Comparator |
| Package | TQFP |
| Country/Region Of Manufacture | Unknown |
| Application | Computer |
TLV3501 is a high-speed comparator. It can be used for waveform shaping of input signal and output TTL level signal. TLV3501 has a fast propagation delay of - 4.5nS, a single power supply of 5V, which is beyond the common mode range of swing input, making it very suitable for low voltage applications, and is an ideal choice for high-speed dagger comparison circuits. The rail-to-rail output can directly drive CMOS or TTL logic. Parameters: 1. Power supply voltage: 5V single power supply 2. Input voltage: 10mVpp~5Vpp (unipolarity) 3. Output level: rail-to-rail output, which can directly drive TTL/CMOS level 4. Input frequency: DC-120MHz 5. Interface Form: SMA (Outer Screw Inner Hole) 6. Input impedance: 50 Ω configurable Parameters: 1. Power supply voltage: 5V single power supply 2. Input voltage: 10mVpp~5Vpp (unipolarity) 3. Output level: rail-to-rail output, which can directly drive TTL/CMOS level 4. Input frequency: DC-120MHz 5. Interface Form: SMA (Outer Screw Inner Hole) 6. Input impedance: 50 ohms configurable 7. Three ways of comparison: comparison with the same signal, comparison with the anti-signal, comparison with the same signal and the anti-signal 8. With shielding cover
