Teco 3/4 HP Farm Duty Electric Motor 1750RPM 115/230V 1 Ph TEFC Frame 56
USD 185.00 USD
Specifications
| Rated/Full-Load Torque | high torque |
| Inverter/Vector Duty Rating | Inverter Duty |
| Full Load Amps | 6.1 |
| Rated Load (HP) | 3/4hp |
| Base RPM | 1750 |
| Shaft Type | Keyed |
| AC Motor Type | Induction/Asynchronous |
| Shaft Diameter | 5/8 in |
| MPN | SO/74 CH0014 |
| Insulation Class | B (Max 266°F) |
| Mounting Type | Base-Mounted |
| Brand | TECO BY WESTINGHOUSE |
| Reversible/Non-Reversible | Reversible |
| Nominal Rated Input Voltage | 230 V, 115 V |
| Model | ARGHPE |
| AC Phase | Single Phase |
| Protection Against Solids | Dust Protected |
The Teco 3/4 HP Farm Duty Electric Motor is a high torque, 1-phase motor designed for industrial automation and motion control applications. With a rated load of 3/4hp and a full load amps of 6.1, this motor offers reliable performance. The TEFC (Totally Enclosed Fan Cooled) frame 56 motor has a base RPM of 1750 and a keyed shaft diameter of 5/8 inches, making it suitable for various mounting types. It also features protection against dripping and splashing water, ensuring durability in harsh environments. This motor, branded by TECO BY WESTINGHOUSE, is ideal for general purpose motor applications requiring a high level of performance and efficiency.
