MKP Capacitor 0.68-47uf ±5% 250V – Audio Grade – Speaker Crossover Film Cap
Specifications
| Return Shipping Will Be Paid By | Seller |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Brand | Unbranded |
| Mounting Style | PCB Mount |
| Series | MKP |
| Type | Film Capacitor |
| Tolerance Rating | ±5 % |
| Termination Style | Axial |
| Capacitance Rating | Multiple Values |
| Material | Polypropylene |
| Maximum Operating Temperature | 85 °C (185 °F) |
| Minimum Operating Temperature | -40 °C (-40 °F) |
| Maximum Operating Voltage | 250 V |
Audio Grade Metallized Polypropylene Foil, Axial-Type, Non-Polarized Capacitors. High current capacity, excellent frequency characteristics, low-ESR and low dissipation factor. Suitable for use in loudspeaker crossovers, replacements or upgrades for coupling capacitors signal path of amplifiers or other audio equipment and as general purpose film filtering capacitors when needing low ESR and high current capability. Specifications: Voltage Rating: 250VDCCapacitance Tolerance: ±5% (J)Dissipation Factor: 0.08% Max at 1KHZOperating Temperature Range: -40C - +85CInsulation Resistance: >10000MΩLead Length ≥32mm Dimensions (Height x Width x Length):0.68uF - (8mm x 14mm x 20mm), ±1mm1.0uF - (8mm x 14mm x 21mm), ±1mm1.5uF - (7mm x 13mm x 26mm), ±1mm1.8uF - (8mm x 15mm x 26mm), ±1mm2.2uF - (8mm x 16mm x 26mm), ±1mm2.7uF - (8mm x 16mm x 32mm), ±1mm3.3uF - (9mm x 17mm x 32mm), ±1mm4.7uF - (11mm x 19mm x 32mm), ±1mm5.6uF - (13mm x 21mm x 32mm), ±1mm6.8uF - (13mm x 21mm x 36mm), ±1mm8.2uF - (14mm x 22mm x 36mm), ±1mm10uF - (15mm x 25mm x 36mm), ±1mm12uF - (14mm x 23mm x 46mm), ±1mm15uF - (15mm x 20mm x 46mm), ±1mm18uF - (18mm x 28mm x 46mm), ±1mm20uF - (18mm x 28mm x 46mm), ±1mm22uF - (22mm x 32mm x 46mm), ±1mm33uF - (27mm x 36mm x 46mm), ±1mm47uF - (27mm x 36mm x 56mm), ±1mm The majority of these capacitors that I've tested measure within ±3% of their stated value. If you receive one that measures outside of the rated ±5% message me and I'll send a tested replacement that is within spec or issue a full refund. The ESR from the capacitors I've tested measured comparably to those of equivalent value from well known crossover component brands such as Dayton Audio, Jantzen and Audyn. Mix and Match, $5 Flat Rate shipping per order on any quantity or selection of qualifying items added to your cart.
