Milwaukee 48-20-5420 SDS Max Hammer Drill Core Bit 3-1/8″ x 11-3/8″L
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 60 Days |
| Refund Will Be Given As | Money Back |
| Overall Length | 11-3/8" |
| Weight | 2.94 |
| Length | 16.300 |
| Width | 4.000 |
| Battery Included | N/A |
| Shank Size | 45/64" |
| Bit Dia. | 3-1/8" |
| Shank Shape | SDS Max |
| MPN | 48-20-5420 |
| Brand | Milwaukee |
Milwaukee 1-3/4 in. x 11-3/8 in. One Piece SDS-MAX Core Bit Model Number: 48-20-5420 Milwaukees one piece carbide tipped core bits are ideal for drilling large holes where the depth is relatively shallow. The core bit cuts a kerf only. The inside core must be removed by the operator before deeper drilling can be accomplished. Use of centering bit 48-20-5495 is recommended (not included). Use drift key 48-20-5497 to remove centering bit from the one piece core bit. The one piece core bits are available in SDS-Max or Spline shanks. They come in a variety of diameters ranging from 1-1/2 in. to 6 in. with overall lengths of 11-3/8 in. or 22 in. and a drilling depth of 3 in.. The asymmetric tooth pitch with alternating tooth geometries creates faster material pulverization. The one piece design maximizes energy transfer and the thick wall core body is durable even in large hammers. The fluted core exterior minimizes friction loss and removes debris faster. Features:Asymmetrical and Alternating Teeth for Faster Material PulverizationThick-Wall Core Body for Durability Even in Large HammersCentering Tip to Reduce Bit Walking and Create Exact Spot Drilling Specifications:Diameter 1-3/4 in.Length 11-3/8 in.Useable Length 3 in. Includes:(1) 1-3/4 in. x 11-3/8 in. One Piece SDS-MAX Core Bit (48-20-5420)
