M170EG01-V9, 17 inch AUO LCD screen
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Brand | NEC |
This refurbished AUO M170EG01-V9 LCD screen has been replaced with our new CCFL backlight lamps, new polarize film and tested. There are no scratches and no pressure marks on the screens. 30 days money back guaranteed! Like new conditions! 90 days warranty AUO M170EG01-V9, one of the most popular LCD panels in an industrial application. This 17 inch AUO M170EG01-V9 is originally equipped with dual CCFL back light lamps. To extend its life and improve its performance, upgrading it to our UB70345LED4221X2 LED kit is the best option. As they are a solid state semiconductor device, LED has a longer lifespan, typically lasting over 100,000 hours. Six pin pigtail connector is included. It is easy to Install! Anyone can do it! How to Connect LED upgrade kit for AUO M170EG01-V9 is Listed below General Specifications: Item Unit Specifications Screen Size [inch] 17 Native Resolution 1280 X 1024 Active Area [mm] 337.920(H) X 270.336(V) Outline dimension [mm] 358.5(W) X 296.5(H) X 17.0(D) Bolt Hole Dimension [mm] 240 X 261 Input Voltage VDD [Volt] 5V Screen Wire Harness FIX-30S-2LVDS Electrical Interface LVDS (8-bit) White Luminance [cd/m2] 420 Contrast Ratio 500:1 BackLight Connector BHSR-02VS-1X4 Backlight Inverter Substitute MS30DI Response time, Rising msec 6 Response time, Falling msec 2 Viewing Angle - Horizontal degree 70 Viewing Angle - Vertical degree 80 Compatible with MS170RBHSR02X4FIX30D1 LCD controller kit FIX-30S-2LVDS_1280X1024 LED Backlight kit UB70345LED4221X2 Direct Replacement LCD MS170RUBFIX30D1
