Keysight/Agilent/HP 54701A Active Probe
Specifications
| All Returns Accepted | ReturnsNotAccepted |
| Brand | Agilent |
| MPN | 54701A |
Keysight/Agilent/HP 54701A Active ProbeThe Agilent 54701A 2.5-GHz Active Probe is a probe solution for high-frequency applications. This probe is designed to be powered from a connector at the front of the oscilloscope, or with the 1143A Probe Offset Control and Power Module. It can be used with any measuring instrument with a 50-Ω input.The 54701A is an Active Probe from Agilent. Use an electrical probe to test equipment and measure currents and voltages. Probes are an integral part of any electrical power testing toolbox to ensure accurate measurements, reliability, and safety. Probes can use pulse waveforms to test components without removing them from circuits with in-circuit capabilities. Choose the probe that complements your system.Additional Features:Attenuation Factor - 10:1Bandwidth (-3dB) - > 2.5 GHzInput Resistance - 100 k ohmsRise Time - < 140 psInput Capacitance - 0.6 pF (typical)Maximum Input Voltage - ± 200 V [DC + peak AC (< 20 MHz)]ESD Tolerance (150 ohms/150 pF) - ± 12 kVDynamic Range - ± 5 V peak AC and ± 50 VDCOffset Adjustment Range - ± 50 V
