JOHNSON CONTROLS M9104-AGA-3S Actuator, Damper, 35 in-lb, 24V AC 41P469
Specifications
| Brand | JOHNSON CONTROLS |
| Type | Electric Actuators |
| Voltage | 24VAC |
| MPN | M9104-AGA-3S |
| Model | M9104-AGA-3S |
Actuator, Valve Application Damper, Signal Type Floating Point, Rated Torque 35 in-lb, Input Voltage 24V AC, Electrical Connection Type Screw Terminals, For Use With Building Automation Systems Building Automation System Compatible, NEMA Rating 1, IP Rating IP40, Spring Return Non-Spring Return, Time to Close 30 sec, Shaft Type Self-Centering Clamping, Shaft Rotation CW/CCW, Stroke Degree 93 Degrees , Mounting Type Direct Mount, Maximum Operating Temperature 140 Degrees F Designed to position balancing, control, round, and zone dampers in HVAC systems. This non-spring return electric actuator is also designed to position blades in a VAV box, or it can be used in VVT 2-position zone applications. Long life brushless synchronous drive motor technology helps provide constant running time inde.
