JB Capacitors – JFX Premium Metallized Polypropylene Film Capacitors – Axial
Specifications
| Return Shipping Will Be Paid By | Seller |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Brand | JB Capacitors |
| Type | Film Capacitor |
| Termination Style | Axial |
| Capacitance Rating | Assorted |
| Maximum Operating Temperature | 85 °C (185 °F) |
| Minimum Operating Temperature | -55 °C (-67 °F) |
The JFX Series capacitors from JB Capacitors are premium metallized polypropylene film capacitors. Their high quality premium audio film capacitors provide unrivaled sound quality JFX - Premium Metallized Polypropylene Film Capacitors – Axial Features Quick transient design High Precise Capacitance Very Low Dielectric absorption factor Very Low Dissipation factor Very Low ESR Very Low Inductance Excellent handling of high current audio pulses Specifications: Voltage Rating: 250 / 400 VDC Capacitance Tolerance: ±5% Dissipation Factor: ≤0.0020 1KHz Operating Temperature Range: -55C - +85C Insulation Resistance: >5000MΩ Leads Diameter: 0.8 / 1mm Tinned Pure Copper Wire Value / Dimensions (Diameter x Length): 1.0uF 250V - 10.5mm x 21mm, ±1mm1.5uF 400V - 13mm x 24mm, ±1mm2.2uF 250V - 13mm x 24mm, ±1mm3.3uF 250V - 16mm x 24mm, ±1mm4.0uF 250V - 17mm x 24mm, ±1mm4.7uF 250V - 18mm x 21mm, ±1mm7.5uF 400V - 25mm x 31mm, ±1mm9.1uF 400V - 24mm x 36mm, ±1mm18uF 400V - 30mm x 46mm, ±1mm41uF 250V - 34mm x 46mm, ±1mm62uF 250V - 38mm x 56mm, ±1mm
