FJX-20-20 | 1 1/4″ Female JIC Crimp On Hose Fitting
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| MPN | FJX-20-20 |
| Brand | Hydraulax |
This item is a FJX-20-20 | 1 1/4" I.D. Hose x 1 1/4" JIC 37 Female Swivel Hydraulic Hose Fitting Item #FJX-20-20 You are buying 1 fitting Material: carbon steel construction with clear trivalent coating to prevent white rust/corrosion Hose I.D. 1 1/4"JIC 37 Tube O.D 1 1/4"Thread 1 - 5/8-12 Designed for use with most hydraulic hoses with one or two layers of braided wire reinforcement, including: DiscountHydraulicHoseWeatherheadGatesAeroquipParker*Other Hoses Meeting the Following SpecificationsHose Type: HT, R1, R2, R3, R5, R16, R17H017, H039, H104, H105, H114, H115, H145, H146, H245, H300, H324, H350, H425, H545C3 G1 G2 M2T M3K 2583 FC211 FC212 FC639301 301LT 381 421 421HT 431 436 451 601SAE 100R1AT SAE 100R2AT SAE 1000R3 SAE 100R5 SAE 100R16 SAE All 100R17 Braided Hose Fittings must be crimped according to DiscountHydraulicHose crimp specifications. These fittings are also compatible with Weatherhead Coll-O-Crimp hose crimpers, and most adjustable hose crimpers (including models from from Dayco, Aeroquip and Gates). *DiscountHydraulicHose fittings are not compatible with Parker Kwik-Krimp non-adjustable hose crimpers. JIC 37 Flare (SAE J514) This connection is very common in fluid power systems. Both the male and female have 37 seats. The seal takes place by establishing a ling of contact between the male flare and the female cone seat. The threads hold the connection mechanically. Nominal sizes and actual thread dimensions are listed below.JIC 37 Dash SizeNominal Tube SizeUNF Thread SizeMale Thread O.D.Female Thread I.D.-021/8"5/16-245/16" (0.31)9/32" (0.27)-033/16"3/8-243/8" (0.38)11/32" (0.34)-041/4"7/16-207/16" (0.44)13/32" (0.39)-055/16"1/2-201/2" (0.50)15/32" (0.45)-063/8"9/16-189/16" (0.56)17/32" (0.51)-081/2"3/4-163/4" (0.75)11/16" (0.69)-105/8"7/8-147/8" (0.88)13/16" (0.81)-123/4"1 1/16-121 1/16" (1.06)1" (0.98)-147/8"1 3/16-121 3/16" (1.19)1 1/8" (1.10)-161"1 5/16-121 5/16" (1.31)1 1/4" (1.23)-201 1/4"1 5/8-121 5/8" (1.63)1 9/16 (1.54)-241 1/2"1 7/8-121 7/8" (1.88)1 13/16" (1.79)-322"2 1/2-122 1/2-12" (2.50)2 7/16" (2.42) The 37 flare hydraulic fitting specification was originally developed by the Join Industrial Commission. Though this organization no longer exists this standard is now maintained by the SAE and many users still refer to these fittings as 'J.I.C."We also sell raw hose, fittings, adapters and more. Please see our store for more related products. We have been selling hydraulic hose and fittings for more than fifty years. If you have questions, please contact us by eBay message. Our customer service representatives are available weekdays from 8:00 AM to 5:30 PM EST.Contact Us For Crimp Fittings! Crimp fittings and field-attachable (reusable) fittings are available in our eBay Store and at DiscountHydraulicHose. If you can't find something, please contact us by eBay message, we carry many other items for hydraulic and pneumatic applications. Looking for other fittings? We have hose fittings, adapters, quick disconnects, gauges and more available in our eBay Store. And of course, we have the very best prices on hydraulic hose.We Combine Shipping! If you are purchasing items from more than one of our listings, please wait and pay for your purchases together, so that we can combine them for shipping. If you pay for your purchases separately, they will be processed separately. We cannot be responsible for combining your order after your payments have been received. Proposition 65 ComplianceWhat is Proposition 65? Proposition 65 requires businesses to provide warnings to Californians about significant exposures to chemicals that cause cancer, birth defects or other reproductive harm. Powered by SixBit's eCommerce Solution
