50 Pcs 1000V 50A Metal Case Single Phase Diode Bridge Rectifier KBPC5010 50X
Specifications
| Return Shipping Will Be Paid By | Seller |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| MPN | KBPC5010 50X |
| Peak Forward Voltage | 1 V |
| Peak Reverse Repetitive Voltage | 1000 V |
| Minimum Operating Temperature | -55 C (-67 F) |
| Country/Region Of Manufacture | China |
| Material | Metal |
| Maximum Operating Temperature | 150 °C (302 °F) |
| Reverse Current | 10 µA |
| Maximum Continuous Current | 50 A |
| Peak Surge Current | 400 A |
| Brand | SEP |
| Mounting Style | Chassis Mount |
| Type | Bridge Rectifier |
50 Pieces KBPC5010 50A 1000V Metal Case Single Phase Silicon Bridge Rectifier This KBPC5010 50A 1000V silicon bridge rectifier features an electrically-isolated metal case for maximum heat dissipation, surge overload rating of 400A, and low voltage drop. KBPC5010 Features:UL listed under the Recognized Component Index, file number E142814The plastic material used carries Underwriters Laboratory flammability recognition 94V-0Surge overload ratings to 400 amperesElectrically isolated metal case for maximum heat dissipationCase to terminal isolation voltage 2500VElectrical Specifications:Maximum repetitive peak reverse voltage (VRRM): 1000VMaximum RMS bridge input voltage (VRMS): 700VMaximum DC blocking voltage (VDC): 1000VMaximum average forward rectified output current at TA=40 C (IF(AV)): 50APeak forward surge current single sine-wave superimposed on rated load (JEDEC Method) (IFSM): 400ATypical thermal resistance per element (ReJA): 2.5 degrees C/WOperating junction and storage temperature range: -55 to +150 CMaximum instantaneous forward voltage drop per leg at 25A (VF): 1.0VMaximum DC reverse current at rated TA=25 C (IR): 10uADC blocking voltage per element TA=125 C (IR): 500uAMechanical Data:Case: Metal caseTerminals: Plated .25"(6.35mm) FastonMounting Position: Bolt down with silicone thermal compound between bridge and mounting surface for maximum heat transfer efficiencyUniversal 4-way terminals, snap-on, wrap-around, solder or P.C. Board mountingMounting Torque: 20 in-lb max.Weight: 1.12 Ounces / 32 grams (approx)Package includes:50x (50 pieces) KBPC5010 50A 1000V Metal Case Single Phase Diode Bridge RectifierLink to online wiring diagram and manufacturer's datasheet Get it faster! Stocks and ships from our US Colorado office for quick delivery! Ships USPS Priority Mail or UPS Shipping for 2-4 Day Delivery - Not Economy Shipping
