(10 Pair) Molex Pin : Male & Female : .093″ : 14-20 AWG : 02-09-1104 :02-09-2103
Specifications
| Return Shipping Will Be Paid By | Seller |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 60 Days |
| Brand | Molex |
| MPN | 02-09-1104 & 02-09-2103 |
| Pin Size: | Standard .093" |
| Gauge | 14-16-18-20 AWG |
| Quantity | 20 Pair |
| Gender | Male & Female |
| Country/Region Of Manufacture | United States |
Welcome, ResourceRiver Introducing our new 60 DAYS Return PolicyMolex - Brings together innovation and technology to deliver electronic solutions to customers worldwide. With a presence in more than 40 countries, Molex offers a full suite of solutions and services for many markets, including data communications, consumer electronics, industrial, automotive, commercial vehicle and medica Molex: Male & Female Crimp Type, 0.093" Terminals Overview A solid mechanical connection is ideal for any cable connection, this 0002091104 connector contact manufactured from Molex will get the job don. It has a socket type gender. It has a straight body orientation. This device has a maximum current rating of 17 A. This has a Connector Headers and PCB Receptacles connector. This product is 21.97 mm long, 4.83 mm tall and 5.33 mm deep. Its wire is 14-20 AWG. This connector contact has a minimum operating temperature of -40 °C and a maximum of 105 °C. It uses the crimp termination method. Item Specification: 0.093" 14-20 AWG:Pin Size: Standard .093" 14-20 AWGPitch - Mating Interface = .248" (6.30mm)Made in USA Part Number: 02-09-1104Part Number: 02-09-21042.36mm Diameter, Standard .093" Pin and Socket Crimp Terminal, Series 1189, Female, with Tin (Sn) Plated Brass Contact, 14-20 AWG. What is included:Qty:10 Male of Molex Wire gauge 14 16 18 20 (Strip/Reel Packaging) (Extra 2 Pins)Qty:10 Female of Molex Wire gauge 14 16 18 20 (Strip/Reel Packaging)( Extra 2 Pins) Benefits Strip/Reel Contacts Strip/Reel Packaging Contacts have an easier time handling the terminals while they are attached to the strip. Whenever yours hand are steady or not then maybe this will make things easier for you. Material - MetalBrassMaterial - Plating MatingTinMaterial - Plating TerminationTinPlating min - Mating0.508µmPlating min - Termination0.508µmTermination Interface: StyleCrimp or CompressionWire Insulation Diameter1.65 - 4.06mmWire Size AWG14, 16, 18, 20 ****************************************************
