1/3/5Axis Nema34 Stepper MotorΦ14m 4.5/8.5/12Nm &Driver&60V Power Supply CNC Kit
USD 99.28 USD
Specifications
| Motor Torque* | 4.5Nm(642oz.in) |
| Brand | TEHIGHAUTO |
| MPN | nema34 86 Motor |
| Wiring Configuration | 4-Wire Bipolar |
| Shaft Diameter | 14mm |
| Shaft Type | Keyway |
| Actual Rated Input Voltage | 36-60VDC |
| Country/Region Of Manufacture | China |
| Nominal Rated Input Voltage | 60V |
| Full Step Angle | 1.8° (200 Steps) |
| Insulation Class | B (Max 266°F) |
| IP Rating | Not Rated |
Nema34 1.8 Degree 2Ph 4 Lead Step Motor Kit for CNC 3D Printer Milling Engraving. 1/3/5pcs Nema34 4.5NM/8.5NM/12NM Stepper Motor. 1/3/5pcs Driver. Driver Specifications.
